Shimano RD-7700-EV

RD-7700-EV RD Rear Derailleur - Schaltwerk

Here you will find the spare parts drawing for Shimano RD Rear Derailleur - Schaltwerk RD-7700-EV. Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
1	Y-5TJ98010	B-Axle Assembly (SS-Type) Y5TJ98010
1	Y-5TJ98110	B-Axle Assembly (GS-Type) Y5TJ98110
2	Y-5TJ27000	B-Tension Spring (SS-Type) Y5TJ27000
2	Y-5TJ30000	B-Tension Spring (GS-Type) Y5TJ30000
3	Y-53M21000	B-Tension Adjusting Screw (M4 x 12) Y53M21000
4	Y-5TJ98020	Stroke Adjusting Screws (M4 x 11,5) & Plate Y5TJ98020
5	Y-5TJ98030	Cable Adjusting Bolt Unit Y5TJ98030
6	Y-5TJ98040	Cable Fixing Bolt (M5 x 8) & Plate Y5TJ98040
7	Y-5TJ98050	Plate Axle Assembly Y5TJ98050
8	Y-56015100	P-Tension Spring Y56015100
9	Y-5TJ98060	Outer Plate (SS-Type) & Plate Stopper Pin Y5TJ98060
9	Y-5TJ98120	Outer Plate (GS-Type) & Plate Stopper Pin Y5TJ98120
10	Y-55919000	Plate Stopper Pin Y55919000
11	Y-53M24000	Pulley Bolt Y53M24000
12	Y-5TJ98080	Guide Pulley Unit (SS-Type) Y5TJ98080
12	Y-5TJ98140	Guide Pulley Unit (GS-Type) Y5TJ98140
13	Y-5TJ98090	Tension Pulley Unit (SS-Type) Y5TJ98090
13	Y-5TJ98160	Tension Pulley Unit (GS-Type) Y5TJ98160
14	Y-5TJ08000	Inner Plate (SS-Type) Y5TJ08000
14	Y-5TJ09000	Y5TJ09000
