Shimano CS-R8101-12 ULTEGRA Cassette (12-speed)

CS-R8101-12 ULTEGRA Cassette (12-speed) CS Cassette / Zahnkranz

Here you will find the spare parts drawing for Shimano CS Cassette / Zahnkranz CS-R8101-12 ULTEGRA Cassette (12-speed). Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
1	Y-0UJ98010	Lock ring and washer for CS-R8101 Y0UJ98010
1	Y-0NR98010	Lock ring and washer for CS-R8100 Y0NR98010
2	Y-10Z04000	Lock ring washer Y10Z04000
3	Y-0MV11000	Sprocket 11T C (built in spacer type) Y0MV11000
4	Y-0UJ9801T	Sprocket 12T E (built in spacer type) for CS-R8101/R8100 Y0UJ9801T
4	Y-0MV12000	Sprocket 12T E (built in spacer type) for CS-R8100 Y0MV12000
5	Y-0MV13000	Sprocket 13T D Y0MV13000
6	Y-0NR14000	Sprocket 14T D Y0NR14000
7	Y0UJ9802T	Sprocket 15T D for CS-R8101/R8100 Y0UJ9802T
7	Y-0NR15000	Sprocket 15T D for CS-R8100 Y0NR15000
8	Y-0MV16100	Sprocket 16T E Y0MV16100
9	Y-0NR98020	Sprocket unit (17-19T) for 11-30T Y0NR98020
10	Y0UJ98020	Sprocket unit (21-24-27-30T) for CS-R8101/R8100 11-30T Y0UJ98020
10	Y-0NR98030	Sprocket unit (21-24-27-30T) for CS-R8100 11-30T Y0NR98030
11	Y-0MV40020	Spacer A Y0MV40020
12	Y-0NR00200	Spacer B Y0NR00200
13	Y-0MV01000	Adhesive ring Y0MV01000
14	Y-0NR98040	Sprocket unit (17-19T) for 11-34T Y0NR98040
15	Y-0UJ98030	Sprocket unit (21-24-27-30-34T) for CS-R8101/R8100 11-34T Y0UJ98030
15	Y-0NR98050	Sprocket unit (21-24-27-30-34T) for CS-R8100 11-34T Y0NR98050
16	Y-13098730	TL-SR24 Sprocket remover tool Y13098730
17	Y-12009230	TL-LR15 Lock ring removal tool Y12009230
