Shimano FD-M8070 DEORE XT Down Swing Front Derailleur (2x11-speed)

FD-M8070 DEORE XT Down Swing Front Derailleur (2x11-speed) FD Front Derailleur - Umwerfer

Here you will find the spare parts drawing for Shimano FD Front Derailleur - Umwerfer FD-M8070 DEORE XT Down Swing Front Derailleur (2x11-speed). Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
1	Y-5R5070D0	Adjust Plate Y5R5070D0
2	Y-5ZP00051	Adjust Screw Y5ZP00051
3	Y-5R5070C0	Stroke Fixing Bolt Y5R5070C0
4	Y-5ZP00020	Stroke Fixing Plate Y5ZP00020
5	Y-7DE18000	E-Ring D2 Y7DE18000
6	Y-5ZP00017	Rubber Pad B Y5ZP00017
7	Y-5R5070S0	Bracket Fixing Bolt Y5R5070S0
8	Y-5R007000	Clamp Bolt (M5 x 18.5) for SM-FD905H / SM-FD905L Y5R007000
9	Y-57Y98030	Clamp Band Adapters for S-size / Diameter 28.6 mm Y57Y98030
9	Y-57Y98040	Clamp Band Adapters for M-size / Diameter 31.8 mm Y57Y98040
10	Y-5R230000	Clamp Bolt (M6 x 14.5) for SM-FD905D Y5R230000
11	Y-5R5070T0	Plug Cover Y5R5070T0
