Shimano BR-T610 DEORE

BR-T610 DEORE BR Brake - Bremse

Here you will find the spare parts drawing for Shimano BR Brake - Bremse BR-T610 DEORE. Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
1	Y-8EM07100	Link Fixing Bolt (M6 x 16) Y8EM07100
1	Y-8EM07110	Link Fixing Bolt (M6 x 25) Y8EM07110
2	Y-8B098030	Shoe Fixing Nut Unit Y8B098030
3	Y-8GV05000	Spring Tension Adjustment Screw (M3 x 8) Y8GV05000
4	Y-81L98010	S70C Cartridge-Type Brake Shoe Set (Pair) for BR-T610-S Y81L98010
4	Y-81L98020	S70C Cartridge-Type Brake Shoe Set (Pair) for BR-T610-L Y81L98020
4	Y-81L98030	M70CT4 Cartridge-Type Brake Shoe Set (Pair) for BR-T610-S Y81L98030
4	Y-81L98040	M70CT4 Cartridge-Type Brake Shoe Set (Pair) for BR-T610-L Y81L98040
5	Y-8AA98130	S70C Cartridge-Type Brake Shoes & Fixing Pins (Pair) Y8AA98130
5	Y-8A298060	M70CT4 Cartridge-Type Brake Shoes & Fixing Pins (Pair) Y8A298060
6	Y-8KW98010	S70T Cartridge-Type Brake Shoe Set (Pair/Option Y8KW98010
7	Y-8B098020	Cable Fixing Bolt (M6 x 11.5) & Fixing Plate Y8B098020
8	Y-8FM05000	Boot Y8FM05000
9	Y-8AA98070	Inner Cable Lead Unit (90 : Middle) Y8AA98070
9	Y-8AA98080	Inner Cable Lead Unit (135 : Long) Y8AA98080
9	Y-8AA98120	Inner Cable Lead Unit (45 : Short) Y8AA98120
