Shimano BR-M485-R-2765 Rear Disc Brake Scheibenbremse Hinten

BR-M485-R-2765 Rear Disc Brake Scheibenbremse Hinten BR Brake - Bremse

Shimano BR Brake - Bremse BR-M485-R-2765 Rear Disc Brake Scheibenbremse Hinten

Here you will find the spare parts drawing for Shimano BR Brake - Bremse BR-M485-R-2765 Rear Disc Brake Scheibenbremse Hinten. Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

PosArticle NumberDescription
01 Y-8H298010Connecting Bolt Unit Y8H298010
02 Y-8H298020Olive & Connecting Insert Y8H298020
03 Y-8H203010Cover Y8H203010
04 Shimano TL-BH61 Special Tool (2 pcs.)Y-8H198030TL-BH61 Special Tool (2 pcs.) Y8H198030
05 Y-83098040SM-HANG Hose Supporter A & B Y83098040
06 Shimano Bleed Nipple CapY-8B214000Bleed Nipple Cap Y8B214000
07 Y-8ES98020Bleed Nipple & Seal Ring Y8ES98020
08 Y-8CL24100Bleed Nipple Y8CL24100
09 Shimano O-Ring for Bleed NippleY-8B511000O-Ring for Bleed Nipple Y8B511000
10 Shimano Adapter Fixing Bolt (M6 x 18.7) & Stop RingY-8DS98010Adapter Fixing Bolt (M6 x 18.7) & Stop Ring Y8DS98010
11 Y-8C511000Stop Ring Y8C511000
12 Y-8C509020Adapter Fixing Bolt (M6 x 18.7) Y8C509020
13 Y-8DB10100A-Standard Mount Adapter for Disc Rotor 160 mm Y8DB10100
14 Y-8DB06000Split Pin Y8DB06000
15 Y-8ES98010Resin Pad (B01S) & Spring Y8ES98010
16 Y-8C515000Pad Spacer Y8C515000
17 Y-8HM98010SM-RT53 Disc Rotor Unit ( 160 mm) Y8HM98010
17 Y-8HM98030SM-RT53M Disc Rotor Unit ( 180 mm) Y8HM98030
17 Y-8HM98050SM-RT53L Disc Rotor Unit ( 203 mm) Y8HM98050
18 Y-8HS98030Lock Ring & Washer Y8HS98030
19 Shimano TL-LR15 Lock Ring Removal ToolY-12009230TL-LR15 Lock Ring Removal Tool Y12009230
20 Y-83998010Mineral Oil Bleed Kit (50 ml) Y83998010
