Shimano BR-M430 V-Brake

BR-M430 V-Brake BR Brake - Bremse

Here you will find the spare parts drawing for Shimano BR Brake - Bremse BR-M430 V-Brake. Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
01	Y-82N18800	Link Fixing Bolt (M6 x 16) Y82N18800
02	Y-8B098010	Spring Tension Adjustment Screw (M4 x 7) & Stopper Y8B098010
03	Y-8B098030	Shoe Fixing Nut Unit Y8B098030
04	Y-8C898020	S70C Cartridge-Type Brake Shoe Set (Pair) Y8C898020
05	Y-8AA98130	S70C Cartridge-Type Brake Shoes & Fixing Pins (Pair) Y8AA98130
06	Y-8C898030	M70R2 Cartridge-Type Brake Shoe Set (Pair) for M-System Y8C898030
07	Y-8AA98020	M70R2 Cartridge-Type Brake Shoes & Fixing Pins (Pair) for M-System Y8AA98020
08	Y-8B098020	Cable Fixing Bolt (M6 x 11.5) & Plate Y8B098020
09	Y-8BP14000	Boot Y8BP14000
10	Y-8AA98070	Inner Cable Lead Unit (90 : Middle) Y8AA98070
10	Y-8AA98080	Inner Cable Lead Unit (135 : Long) Y8AA98080
10	Y-8AA98120	Inner Cable Lead Unit (45 : Short) Y8AA98120
